4Kx2K 2.0 HDMI Matrix 4x4, support 3D, RS232, EDID

NS-MX4x4-V2.0

New product

The HDMI 2.0 Matrix 4x4 can connect four HDMI signal sources with the four displays at the same time. It can easily and freely split or switch four HDMI signals on four displays or projectors which compatible with HDMI signal. Extra infrared receiver extension, IR emitter, RS232 are supplied for remote control.

More details

More info

Features

  • Support HDMI 2.0
  • Support 3D
  • Support IR Remote Control
  • Support RS232 Control
  • The 4 outputs could show the same or different source simultaneously
  • Support 4K (Input) resolution 2K (Output) (Downscaling)

Package Content

  • HDMI 2.0 Matrix 4x4              x1
  • IR Remote Control                 x1
  • 12V/2A DC Power Adapter    x1
