1x4 Ultra Slim HDMI 2.0 Splitter with EDID (4:4:4)

NS-104SP-S2.0

New product

This 1 by 4 HDMI UHD Splitter with HDCP 2.2 is an advanced solution for splitting a single HDMI input to four HDMI outputs. It provides high performance audio and video output through HDMI cables up to 4K2K@60Hz (YUV444) resolution and is capable of receiving and transmitting up to 18Gbps of bandwidth with no data loss.

More details

More info

Features

  • Compliant with HDMI2.0, HDCP2.2 and DVI 1.0
  • Support video format up to 4k2k@30Hz with 24bit RGB/YcbCR 4:4:4/YCBCR 4:2:2,and up to 4k2k@60Hz with 12bit YCBCR 4:4:4
  • Support 3D frame sequential video format up to 1080p@60
  • Support high resolution VESA mode video format up to QSXGA@60Hz
  • Supports LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio
  • Supports smart EDID control

Package Content

  • 1x4 HDMI Splitter x1
  • Power adapter x1
  • User Manual x1
